The UY CHAN TS101 Portable Programmable Soldering Iron is an advanced upgrade to the classic TS100, specifically designed for mobile technicians and hobbyists. This pocket-size tool features a dual power input system that accepts both a traditional DC5525 barrel jack and a modern USB Type-C PD port. With a versatile operating voltage range of 9-24V for DC and 9-20V for PD, it can deliver up to 65W of power for rapid heating. Its compact, ergonomic handle is equipped with a high-definition OLED screen that displays real-time temperature data and voltage status, ensuring precise control during intricate field repairs.
Efficiency is a core feature of the UY CHAN TS101 Portable Programmable Soldering Iron, which offers an adjustable temperature range of 50 to 400 degrees Celsius. The device is powered by a smart chip that includes acceleration sensors and dual-temperature sensors for stable thermal management. Users can benefit from intelligent functions such as automatic sleep mode, overheat warnings, and a newly integrated boost function for quickly tackling larger solder joints. Additionally, the open-source firmware allows for deep customization, enabling users to program unique heating curves and menu settings by connecting the device to a computer.
Designed for convenience and longevity, the UY CHAN TS101 Portable Programmable Soldering Iron features a square handle design to prevent rolling and a user-friendly tip replacement system that is backward compatible with original TS100 tips. This package is sold as a standalone unit without a power supply, making it a perfect addition for those who already own compatible 12-24V batteries, power banks, or laptop adapters. Its lightweight construction and anti-slip cap make it a reliable companion for drone maintenance, circuit board repair, and various electronic projects where portability and professional performance are required.
FEATURES:
– Upgraded from TS100
– Type C PD input
– DC power input
– Programmable settings
– 50-400C temperature range
– Adjustable temperature control
– Pocket-size design
– Portable for field repair
The UY CHAN TS101 Portable Programmable Soldering Iron represents a significant leap in mobile repair technology, serving as the official upgraded successor to the classic TS100 model. This compact tool features a sleek, ergonomic design that prioritizes user comfort while maintaining a pocket-sized form factor ideal for technicians on the move. It integrates a dual power input system, supporting both DC and USB-C Power Delivery, which allows for versatile operation in various environments ranging from professional laboratories to remote field locations.
– Heats up super fast
– Easy to control
– Useful stand and accessories
– Includes XT60 battery adapter
– Adequate power supply
– Fast enough for quick jobs
– Very fine soldering tip
– Compact and portable size
– Supports custom firmware
– Compatible with various power sources
– Excellent temperature control
– Great for field repairs
– High build quality
– Powers via USB-C and DC
– Stiff power supply wire insulation
– ESD strap is rarely used
– Needs custom firmware for features
– Included B2 tip isn’t for everyone
– Battery adapters can drain batteries
The UY CHAN TS101 is a highly portable and fast-heating soldering iron ideal for field repairs due to its compact size, high build quality, and versatile power options including USB-C and DC inputs. Users benefit from excellent temperature control, a fine soldering tip, and compatibility with custom firmware, though the device’s full potential often requires that software upgrade. While it includes helpful accessories like an XT60 adapter and a useful stand, drawbacks include stiff wire insulation on the power supply, an included B2 tip that may not suit all tasks, and the potential for battery adapters to drain power sources if left connected. would you like me to compare this model to other portable soldering irons on the market? Read more…
Versatile Digital Soldering Iron Applications
A promotional graphic shows a digital soldering iron in various settings. The main image features a hand holding a sleek black soldering tool with an integrated OLED display showing a temperature of 330 degrees Celsius. Four smaller panels illustrate specific use cases for the device. The top left panel shows appliance repair with a focus on internal wiring. The top right panel depicts a person working on a green circuit board with visible smoke from the solder. The bottom left panel displays the tool being used inside a computer tower for electronic device maintenance. The bottom right panel is labeled DIY pyrography and shows the tool being used on a complex motherboard. Each panel includes a descriptive orange label at the bottom. The text Widely Usage is printed in large bold yellow letters at the top of the image. The background is dark and emphasizes the precision of the tool.
TS101 Dual Power Input Soldering Iron Features
This image displays the TS101 soldering iron and its power specifications. It features two different input ports for power. The device supports both DC and USB PD power sources. The DC input range is between 9 and 24 volts with a 65 watt maximum. The PD input range is between 9 and 20 volts with a 45 watt maximum. Four smaller images on the right side show various power options. These options include a DC power adaptor and a USB charger plug. Users can also power the tool with a Lipo battery or a portable power bank. A note at the bottom states that DC and PD inputs cannot be used simultaneously. The tool is designed to be portable and versatile for different environments. The sleek grey handle includes a small digital display screen. This iron is advertised as fast to melt tin for multiple applications.
Upgraded TS101 Smart Soldering Iron Features
This image shows a comparison between the Upgraded TS101 and the Classic TS100 soldering irons. The TS101 features a brand new look with a wider screen and a textured grip. It supports dual power input through both DC and USB PD ports. This model is compatible with original TS100 soldering tips. The design allows for fast heating and easy disassembly. One inset shows the top of the iron with the two power ports clearly visible. Another inset displays the iron disassembled into its handle and tip components. The background uses orange and blue gradients to separate the new model from the old one. Text highlights indicate that the device is compact and takes up very little space.
Portable Digital Soldering Iron with Smart Control
A person holds a sleek grey digital soldering iron over a computer motherboard. The iron features a small OLED screen and physical control buttons. A black power cable is plugged into the top of the device. The background shows five feature icons including auto sleep and accurate temperature control. Large white and orange text at the bottom reads Accurate Control and Rewarming Rapid. The motherboard is filled with various electronic components like capacitors and heat sinks. The person’s hand is positioned to perform precise work on the circuit board. The overall lighting is cool and professional. This image highlights the modern technology used in electronics repair and soldering tasks.
A Smart Portable Soldering Iron Kit
This image shows a modern portable soldering iron and its components. The main body is a sleek dark gray handle with a digital display. It features small buttons for temperature control. A separate metal soldering tip lies next to the handle. This tip has a standard jack connector for easy installation. A small black silicone cap or stand sits in the foreground. The design is compact and ergonomic. All items are placed on a clean white surface. The lighting is bright and professional. This tool is designed for precision electronics work. It looks like a high-end device for makers and engineers.
TS-B2 Replacement Soldering Tip Specification
This image displays a TS-B2 replacement soldering iron tip designed for portable digital soldering irons. The main component is a long and slender metallic shaft with a conical heating point. A technical line drawing at the top left shows the tip dimensions with a length of 10.0 millimeters. The central portion of the tool features a wider flange for secure seating into the handle. The top end includes a white ceramic insulator and metallic contact rings for power delivery. Blue text at the bottom provides specific technical details including the model number TS-B2. The total length of the component is listed as 105 millimeters. The weight of the individual tip is 10.5 grams. A zoomed-in view in the bottom right corner highlights the precision of the pointed tip. The overall design is professional and intended for electronics repair tasks.
Miniware TS101 Smart Soldering Iron Packaging
The image shows the retail packaging for a Miniware TS101 smart soldering iron. The box is rectangular and matte black. It features white and orange design elements. The front face displays the model name TS101 in large bold white letters. A high-resolution photo of the soldering iron is printed on the right side. Dimension lines indicate the package size is 140mm in length. The height is labeled as 80mm and the depth is 35mm. The Miniware logo is visible in the top left corner. The background is a clean white studio setting with soft shadows. The overall presentation is professional and modern.
Portable Digital Soldering Iron and Electronics Workspace
A person holds a sleek portable digital soldering iron over a black surface. The soldering iron features a small integrated display screen and control buttons. It is connected to a power source by a black cable. In the background a computer motherboard sits on the left side. A small green drone with orange propellers is positioned in the center. The workspace is dark and minimalist. The lighting focuses on the hand and the soldering tool. The person holds the device like a pen for precision work. This setup suggests a modern electronics repair or hobbyist environment. The overall composition is clean and professional.
